8.01 Protocol Command List

The table below lists features speciﬁc to IRIS116 Series (116,117,118) Cameras that are not covered by the standard Pelco-D protocol

and the commands that have been mapped in IRIS camera software to operate those features. Values are shown in hexadecimal. The

checksum for all Pelco-D commands is the 8 bit (modulo 256) sum of the payload bytes (bytes 2 ~ 6) within the message. Refer to the

Pelco-D protocol document for further information.

For more in depth information on Iris Protocol mapping please contact Iris Innovations.

Function

Value

Command

Add

CHK

Day / Night Model Manual Toggle

Preset 21

CHK

Day / Night Mode Auto

Preset 22

CHK

WDR Toggle On/Off

Preset 23

CHK

Auto WDR

Preset 24

CHK

BLC Manual Toggle

Preset 25

CHK

Image Flip Toggle (Vertical)

Preset 26

CHK

DNR Toggle

Preset 27

CHK

Video Freeze Toggle (117 & 118)

Preset 28

CHK

Video Freeze (116)

Preset 234

CHK

Video Resume (116)

Preset 235

CHK

Defogger ON (117 & 118)

Preset 37

CHK

Defogger OFF (117 & 118)

Preset 38

CHK

Digital Zoom Toggle (117 & 118)

Preset 39

CHK

OSD Toggle (117 & 118)

Preset 40

CHK

Frame Scan Boundary LEFT

Preset 42

CHK

Frame Scan Boundary RIGHT

Preset 43

CHK

Random Scan ON

Preset 48

CHK

Frame Scan ON (117 & 118)

Preset 49

CHK

IR LEDʼs ON (118)

Preset 32

CHK

IR LEDʼs OFF (118)

Preset 33

CHK

White LEDʼs ON (117)

Preset 72

CHK

White LEDʼs OFF (117)

Preset 73

CHK

Image Flip UP (116)

Preset 236

CHK

Image Flip Down (116)

Preset 237

CHK

45˚ Auto Scan (116)

Slow

CHK

Medium

CHK

Fast

CHK

90˚ Auto Scan (116)

Slow

CHK

Medium

CHK
